| Quantity: | |
|---|---|
Packing Specifications
Type of Cylinder | Content | |
Capacity | Valve | Weight |
40L | CGA 590/QF-2 | 50KG |
47L | CGA 590/QF-2 | 58KG |
50L | CGA 590/QF-2 | 62KG |
500L | CGA 590/QF-2 | 625KG |
Industrial SF6 99.995%
Specification | ≥99.995% |
Air | ≤ 10 ppm |
CF₄ | ≤ 2 ppm |
C2F6 | ≤ 20 ppm |
C3F8 | ≤ 5 ppm |
Low sulfide | Not Detected |
Moisture | ≤ 1 ppm |
HF | ≤ 0.1 ppm |
Hydrofluoric acid hydrolysis of fluoride | ≤ 0.3 ppm |
Mineral oil | ≤ 1 ppm |
Electronic SF6 99.999%
Specification | ≥99.999% |
O2+Ar | ≤ 1 ppm |
N2 | ≤ 2 ppm |
CH4 | ≤ 0.1 ppm |
CO | ≤ 0.5 ppm |
CF4 | ≤ 0.5 ppm |
CO2 | ≤ 0.5 ppm |
Moisture | ≤ 3 ppm |
HF | ≤ 0.1 ppm |
Hydrofluoric acid hydrolysis of fluoride | ≤ 0.8 ppm |
Packing Specifications
Type of Cylinder | Content | |
Capacity | Valve | Weight |
40L | CGA 590/QF-2 | 50KG |
47L | CGA 590/QF-2 | 58KG |
50L | CGA 590/QF-2 | 62KG |
500L | CGA 590/QF-2 | 625KG |
Industrial SF6 99.995%
Specification | ≥99.995% |
Air | ≤ 10 ppm |
CF₄ | ≤ 2 ppm |
C2F6 | ≤ 20 ppm |
C3F8 | ≤ 5 ppm |
Low sulfide | Not Detected |
Moisture | ≤ 1 ppm |
HF | ≤ 0.1 ppm |
Hydrofluoric acid hydrolysis of fluoride | ≤ 0.3 ppm |
Mineral oil | ≤ 1 ppm |
Electronic SF6 99.999%
Specification | ≥99.999% |
O2+Ar | ≤ 1 ppm |
N2 | ≤ 2 ppm |
CH4 | ≤ 0.1 ppm |
CO | ≤ 0.5 ppm |
CF4 | ≤ 0.5 ppm |
CO2 | ≤ 0.5 ppm |
Moisture | ≤ 3 ppm |
HF | ≤ 0.1 ppm |
Hydrofluoric acid hydrolysis of fluoride | ≤ 0.8 ppm |
